Threat Modeling & Risk Management (part 3)

The SecFit Threat Modeling & Risk Management project is part of TDT4237 (Software Security and Data Privacy) at NTNU.
It focused on analyzing and mitigating risks for a web-based cybersecurity risk assessment tool designed to support Air Traffic Management (ATM) systems, using STRIDE threat modeling, misuse cases, and a Data Flow Diagram (DFD) created with OWASP Threat Dragon.

Key Business Assets & Goals

  • Assets: stored risk assessment data, reference lists, and the web tool itself.
  • Goals: simplify risk assessments, improve ATM security and safety, provide a trusted tool.

Business Risks

  • BR01: Unauthorized access to stored risk assessments → High risk.
  • BR02: Tool failure (DoS/server outage) → High risk.
  • BR03: Inaccurate risk scoring → Critical risk.
  • BR04: Loss/corruption of catalog data → Medium risk.
  • BR05: Loss of user trust → Medium risk.

Identified Threats (STRIDE)

  • Spoofing: identity spoofing, login exploitation.
  • Tampering: database modifications, catalog corruption.
  • Repudiation: lack of traceability in frontend actions.
  • Information Disclosure: credential interception, sensitive data leaks.
  • Denial of Service: DoS attacks on catalog or database.
  • Elevation of Privilege: privilege escalation via frontend flaws.

Technical Risks

  • TR1: SQL Injection → SR1: validate/sanitize database queries.
  • TR2: Denial-of-Service → SR2: rate limiting & traffic filtering.
  • TR3: Insecure Data Storage → SR3: encrypt stored data.
  • TR4: Weak Authentication → SR4: enforce MFA & strong passwords.
  • TR5: Insecure APIs → SR5: API authentication & input validation.
  • TR6: Lack of Logging → SR6: tamper-evident logging.
  • TR7: XSS → SR7: sanitize user content & apply CSP.
  • TR8: Outdated Components → SR8: patch & update dependencies.
  • TR9: Unvalidated Inputs → SR9: input validation & allow-lists.
  • TR10: Broken Access Control → SR10: enforce least privilege server-side.

Test Plan Highlights

  • T1: Automated SQL injection testing (SQLMap).
  • T2: Simulated DoS attacks (LOIC, Slowloris).
  • T3: Verify database encryption and unauthorized access prevention.
  • T4: Test brute force attacks & MFA enforcement.
  • T5: API fuzzing & malformed request testing.
  • T6: Logging verification during critical actions.
  • T7: XSS payload testing and CSP enforcement.
  • T8: Dependency scanning & CVE patch verification.
  • T9: Fuzz testing across inputs for injection vulnerabilities.
  • T10: Privilege escalation testing for access control.

Summary of Findings

By combining business risk identification, STRIDE threat modeling, and technical risk analysis, the team derived security requirements and a test plan that improve the resilience of the risk assessment tool.
This structured approach ensures safer operations, stronger system reliability, and higher trust for ATM risk assessments.

Visual Aids

  • Misuse Case Diagram: illustrates unauthorized access scenarios.
  • Data Flow Diagram (DFD): shows data flows, user interactions, and potential attack points.

The full report is available here: Threat Modeling & Risk Management Report (PDF)
